High Flow Cylinder Regulators - CR -60

Product Description

High Flow Cylinder Regulators - CR -60

• This regulator have higher capacity than other common regulators and are designed for use when particularly large flows of gas required

• The large diaphragm is physically separated from main gas stream in order to improve high freeze resistance

• Robust brass body and bonnet combined with stainless-steel inlet stem predetermines regulator for heavy duty applications even in harsh industrial environment.

• Body & bonnet made of forged brass, electro-polished & chemically stabilized

• Diaphragm is of two-layer, fabric reinforced EPDM rubber

• Heart Valves is made of stainless steel body sealed by high-grade PTFE

• Inlet connection is made of high-tensile brass, geometry complying to BS-341 standard

• In this type of regulator safety valve is not present. It is a independent part of downstream gas line

• Pressure gauge is design safely, bulkhead 50mm gauges, scale in Bar, accuracy class 2.5%

• Pressure Setting: Stainless steel T-bar, brass pressure adjusting screw in bronze bush

• DN10 outlet pipe ready for connection of hose
